EP4CE55F23I8L
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
2003 Non-RoHS Compliant BALL Not Qualified FPGA 100C 292.5kB 200MHz 1.24V
PDF
/
Buying Options
Total Price: USD $576.32
Unit Price: USD $576.323713
≥1 USD $576.323713
≥180 USD $229.957061
≥480 USD $222.272657
≥1020 USD $218.47575
Inventory: 8764
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 23mm
Length 23mm
Height Seated (Max) 2.4mm
Technical
Number of Logic Blocks (LABs) 3491
Number of Logic Elements/Cells 55856
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Frequency (Max) 200MHz
RAM Size 292.5kB
Number of I/O 324
Memory Size 292.5kB
Min Supply Voltage 1.16V
Max Supply Voltage 1.24V
Power Supplies 11.2/3.32.5V
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Number of Outputs 327
Pin Count 484
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 1V
Peak Reflow Temperature (Cel) 220
Terminal Form BALL
Terminal Position BOTTOM
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Lead (Sn63Pb37)
Number of Terminations 484
Moisture Sensitivity Level (MSL) 3
Pbfree Code no
JESD-609 Code e0
Published 2003
Physical
Number of Pins 484
Package / Case FBGA
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
