EP4CE30F29I8L
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
2003 Non-RoHS Compliant BALL Not Qualified FPGA 100C 74.3kB 200MHz 1.24V
PDF
/
Inventory: 4863
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Package / Case FBGA
Number of Pins 780
Technical
Published 2003
JESD-609 Code e0
Pbfree Code no
Moisture Sensitivity Level (MSL) 3
Number of Terminations 780
ECCN Code 3A001.A.7.A
Terminal Finish Tin/Lead (Sn63Pb37)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 1V
Terminal Pitch 1mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 780
Number of Outputs 535
Qualification Status Not Qualified
Operating Supply Voltage 1.2V
Power Supplies 11.2/3.32.5V
Max Supply Voltage 1.24V
Min Supply Voltage 1.16V
Memory Size 74.3kB
Number of I/O 532
RAM Size 74.3kB
Frequency (Max) 200MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 28848
Number of Logic Blocks (LABs) 1803
Dimensions
Height Seated (Max) 2.4mm
Length 29mm
Width 29mm
Compliance
RoHS Status Non-RoHS Compliant
