EP3C40F780C8N
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Lead Free CMOS OTHER 2007 FPGA 85C 141.8kB 402MHz 1.25V
PDF
/
Buying Options
Total Price: USD $164.48
Unit Price: USD $164.47825
≥1 USD $164.47825
≥10 USD $147.4628
Inventory: 604
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 29mm
Length 29mm
Height Seated (Max) 3.5mm
Technical
Number of Logic Blocks (LABs) 2475
Number of Logic Elements/Cells 39600
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Frequency (Max) 315MHz
RAM Size 141.8kB
Number of I/O 535
Memory Size 141.8kB
Min Supply Voltage 1.15V
Max Supply Voltage 1.25V
Temperature Grade OTHER
Operating Supply Voltage 1.2V
Number of Outputs 535
Pin Count 780
Time@Peak Reflow Temperature-Max (s) 40
Frequency 402MHz
Terminal Pitch 1mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 245
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Min Operating Temperature 0°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code 3A001.A.7.A
Number of Terminations 780
Moisture Sensitivity Level (MSL) 3
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2007
Physical
Number of Pins 780
Package / Case FBGA
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
