EP3C25Q240C8
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
CMOS OTHER 2007 RoHS Compliant FPGA 85C 74.3kB 402MHz 1.25V
PDF
/
Buying Options
Total Price: USD $159.71
Unit Price: USD $159.7102
≥1 USD $159.7102
≥10 USD $143.18875
Inventory: 1108
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Package / Case PQFP
Number of Pins 240
Technical
Published 2007
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 240
ECCN Code 3A991
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Frequency 402MHz
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 240
Number of Outputs 148
Operating Supply Voltage 1.2V
Temperature Grade OTHER
Max Supply Voltage 1.25V
Min Supply Voltage 1.15V
Memory Size 74.3kB
Number of I/O 148
RAM Size 74.3kB
Frequency (Max) 315MHz
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 24624
Number of Logic Blocks (LABs) 1539
Dimensions
Height Seated (Max) 4.1mm
Length 32mm
Width 32mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
