EP2S90H484C5
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Contains Lead CMOS OTHER 2014 FPGA 70C 620mA 551.8kB 609.76MHz
PDF
/
Buying Options
Total Price: USD $165.53
Unit Price: USD $165.52705
≥1 USD $165.52705
≥10 USD $148.4033
Inventory: 507
Minimum: 1
-
+
Technical Details
Technical
Number of Logic Elements/Cells 60440
Number of Logic Blocks (LABs) 4548
Number of CLBs 36384
Number of Logic Cells 90960
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Organization 36384 CLBS
RAM Size 551.8kB
Number of I/O 308
Operating Supply Current 620mA
Memory Size 551.8kB
Min Supply Voltage 1.15V
Max Supply Voltage 1.25V
Temperature Grade OTHER
Power Supplies 1.21.5/3.33.3V
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Number of Outputs 300
Pin Count 484
Time@Peak Reflow Temperature-Max (s) 30
Frequency 609.76MHz
Terminal Pitch 1mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 220
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code 3A001.A.7.A
Number of Terminations 484
Moisture Sensitivity Level (MSL) 3
Pbfree Code no
JESD-609 Code e0
Published 2014
Dimensions
Height Seated (Max) 3.5mm
Length 27mm
Width 27mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 484
Package / Case BGA
Mount Surface Mount
