EP20K400EFC672-1X
RoHS
/
Package BGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Contains Lead MACROCELL CMOS OTHER FPGA 85C 26kB 1.57ns 368MHz
PDF
/
Buying Options
Total Price: USD $176.14
Unit Price: USD $176.14235
≥1 USD $176.14235
≥10 USD $157.9204
Inventory: 704
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case BGA
Number of Pins 672
Technical
Packaging Bulk
Published 2001
JESD-609 Code e0
Pbfree Code no
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3
Number of Terminations 672
ECCN Code 3A001.A.7.A
Terminal Finish Tin/Lead (Sn63Pb37)
Max Operating Temperature 85°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 1.8V
Terminal Pitch 1mm
Reach Compliance Code not_compliant
Frequency 368MHz
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 672
Number of Outputs 480
Qualification Status Not Qualified
Power Supplies 1.81.8/3.3V
Temperature Grade OTHER
Max Supply Voltage 1.89V
Min Supply Voltage 1.71V
Memory Size 26kB
Number of I/O 488
RAM Size 26kB
Propagation Delay 1.57 ns
Frequency (Max) 180MHz
Programmable Logic Type LOADABLE PLD
Number of Logic Elements/Cells 16640
Number of Gates 1.052e+06
Number of Logic Blocks (LABs) 1664
Output Function MACROCELL
Number of Dedicated Inputs 4
Dimensions
Height Seated (Max) 3.5mm
Length 27mm
Width 27mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
