EP1S40F780C7
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
Contains Lead CMOS COMMERCIAL EXTENDED 2006 FPGA 85C 145mA 417.9kB 420.17MHz
PDF
/
Buying Options
Total Price: USD $447.46
Unit Price: USD $447.46425
≥1 USD $447.46425
Inventory: 51
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 29mm
Length 29mm
Height Seated (Max) 3.5mm
Technical
Number of CLBs 4697
Number of Logic Blocks (LABs) 4125
Number of Logic Elements/Cells 41250
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Organization 4697 CLBS
Frequency (Max) 66MHz
RAM Size 417.9kB
Number of I/O 615
Operating Supply Current 145mA
Memory Size 417.9kB
Min Supply Voltage 1.425V
Max Supply Voltage 1.575V
Temperature Grade COMMERCIAL EXTENDED
Power Supplies 1.51.5/3.3V
Operating Supply Voltage 1.5V
Qualification Status Not Qualified
Number of Outputs 822
Pin Count 780
Time@Peak Reflow Temperature-Max (s) 30
Frequency 420.17MHz
Terminal Pitch 1mm
Supply Voltage 1.5V
Peak Reflow Temperature (Cel) 220
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Field Programmable Gate Arrays
HTS Code 8542.39.00.01
Min Operating Temperature 0°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code 3A001.A.7.A
Number of Terminations 780
Moisture Sensitivity Level (MSL) 3
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Bulk
Physical
Number of Pins 780
Package / Case FBGA
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
