5CSEBA4U23C8N
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description
ARM CMOS OTHER DMA POR WDT FPGA 85C 2.9MB 600MHz 1.1V
PDF
/
Buying Options
Total Price: USD $299.46
Unit Price: USD $299.4571
≥1 USD $299.4571
≥10 USD $268.47855
Inventory: 507
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Package / Case FBGA
Surface Mount YES
Number of Pins 484
Technical
Published 2012
Part Status Active
Number of Terminations 672
Max Operating Temperature 85°C
Min Operating Temperature 0°C
Subcategory Field Programmable Gate Arrays
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 1.1V
Terminal Pitch 0.8mm
Frequency 600MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 672
JESD-30 Code S-PBGA-B672
Number of Outputs 145
Qualification Status Not Qualified
Operating Supply Voltage 1.1V
Supply Voltage-Max (Vsup) 1.13V
Power Supplies 1.11.2/3.32.5V
Temperature Grade OTHER
Interface CAN, EBI/EMI, Ethernet, I2C, MMC, SD, SDIO, SPI, UART, USART, USB
Memory Size 2.9MB
Peripherals DMA, POR, WDT
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 40000
Core Architecture ARM
Dimensions
Height Seated (Max) 1.85mm
Length 23mm
Width 23mm
Compliance
RoHS Status RoHS Compliant
