TMS320VC549PGE-80
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
TMS320C54x MULTIPLE Lead Free Surface Mount DSP -40C~100C TC 64kB 80MHz 1.290414g
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6828
≥1 USD $2.6828
≥10 USD $2.20115
≥100 USD $2.13275
≥500 USD $2.0634
≥1000 USD $1.995
Inventory: 7794
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 20mm
Length 20mm
Height 1.6mm
Technical
Voltage - Core 2.50V
Non-Volatile Memory ROM (32kB)
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 3.30V
RAM (words) 65536
Low Power Mode YES
Boundary Scan YES
Data Bus Width 16b
Bit Size 16
Number of Bits 16
RAM Size 64kB
Memory Size 32kB
Min Supply Voltage 2.4V
Max Supply Voltage 3.6V
Interface BSP, Host Interface, Serial Port
Operating Supply Voltage 3.3V
Pin Count 144
Base Part Number 320VC549
Frequency 80MHz
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Fixed Point
Number of Terminations 144
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series TMS320C54x
Packaging Tray
Operating Temperature -40°C~100°C TC
Physical
Weight 1.290414g
Number of Pins 144
Package / Case 144-LQFP
Mounting Type Surface Mount
Mount Surface Mount
