TMS320VC549PGE-100
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
TMS320C54x MULTIPLE Lead Free Surface Mount DSP -40C~100C TC 64kB 100MHz 1.290414g
PDF
/
Buying Options
Total Price: USD $10.35
Unit Price: USD $10.350416
≥1 USD $10.350416
≥10 USD $9.764547
≥100 USD $9.211833
≥500 USD $8.690405
≥1000 USD $8.198496
Inventory: 1195
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 144-LQFP
Number of Pins 144
Weight 1.290414g
Technical
Operating Temperature -40°C~100°C TC
Packaging Tray
Series TMS320C54x
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 144
ECCN Code 3A991.A.2
Type Fixed Point
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO REQUIRES 3.3V SUPPLY
HTS Code 8542.31.00.01
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Frequency 100MHz
Base Part Number 320VC549
Pin Count 144
Operating Supply Voltage 2.5V
Power Supplies 2.53.3V
Interface BSP, Host Interface, Serial Port
Max Supply Voltage 3.6V
Min Supply Voltage 2.4V
Memory Size 32kB
RAM Size 64kB
Number of Bits 16
Bit Size 16
Data Bus Width 16b
Boundary Scan YES
Low Power Mode YES
RAM (words) 65536
Voltage - I/O 3.30V
Barrel Shifter YES
Internal Bus Architecture MULTIPLE
Non-Volatile Memory ROM (32kB)
Voltage - Core 2.50V
Dimensions
Height 1.6mm
Length 20mm
Width 20mm
Thickness 1.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
