TMS320C6A8168BCYG2
RoHS
RoHS compliant
RoHS compliantPackage 1031-BFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
EBI/EMI Ethernet MAC I2C McASP McBSP SPI UART USB 1031-BFBGA FCBGA 320C6A8168 3A991.A.2 digital signal processor 1.00V 25mm 1.2GHz 64kB
PDF
/
Inventory: 2664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 25mm
Height Seated (Max) 3.31mm
Technical
Clock Rate 1GHz, 1.2GHz
On Chip Data RAM 1.504MB
Voltage - Core 1.00V
Non-Volatile Memory ROM (48kB)
Voltage - I/O 1.5V 1.8V 3.3V
RAM (words) 16384
Integrated Cache YES
Format FLOATING POINT
Low Power Mode YES
Boundary Scan YES
Core Architecture ARM
Address Bus Width 16
Number of Timers/Counters 7
Data Bus Width 32b
Bit Size 32
RAM Size 64kB
Speed 1200 MHz
Memory Size 48kB
Min Supply Voltage 800mV
Max Supply Voltage 1.05V
Interface EBI/EMI, Ethernet MAC, I2C, McASP, McBSP, SPI, UART, USB
Power Supplies 1V
Base Part Number 320C6A8168
Frequency 1.2GHz
Terminal Pitch 0.65mm
Supply Voltage 1V
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Type DSP+ARM?
ECCN Code 3A991.A.2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Series C6A816x
Packaging Bulk
Operating Temperature 0°C~95°C TJ
Physical
Number of Pins 1031
Package / Case 1031-BFBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
