TMS320C6454BZTZA

Texas Instruments
RoHS
/
Package 697-BFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description TMS320C645x MULTIPLE Contains Lead Surface Mount DSP -40C~105C TC 16b 1GHz 4.340114g
PDF
/
Buying Options
Total Price: USD $408.38
Unit Price: USD $408.384251
≥1 USD $408.384251
≥10 USD $394.955748
≥25 USD $392.210282
≥50 USD $389.483893
≥100 USD $381.472962
≥500 USD $354.199599
Inventory: 8553
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Length 24mm
Height Seated (Max) 3.3mm

Technical

On Chip Data RAM 1.08MB
Non-Volatile Memory ROM (32kB)
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 1.2V 1.5V 1.8V 3.3V
RAM (words) 32768
Low Power Mode NO
Boundary Scan YES
Address Bus Width 20
Data Bus Width 16b
Bit Size 32
Memory Type DDR2, SDRAM, SRAM
Number of I/O 16
Min Supply Voltage 1.2125V
Max Supply Voltage 3.46V
Interface Host Interface, I2C, McBSP, PCI, 10/100/1000 Ethernet MAC
Power Supplies 1.2V
Operating Supply Voltage 1.25V
Pin Count 697
Base Part Number 320C6454
Frequency 1GHz
Terminal Pitch 0.8mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Fixed Point
ECCN Code 3A991.A.2
Number of Terminations 697
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e1
Series TMS320C645x
Packaging Tray
Operating Temperature -40°C~105°C TC

Physical

Weight 4.340114g
Number of Pins 697
Package / Case 697-BFBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
