TMS320C50PQ57
RoHS
RoHS compliant
RoHS compliantPackage 132-BQFP Bumpered
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
TMS320C5x MULTIPLE Contains Lead Surface Mount DSP 0C~70C TA 20.1kB 57MHz 4.608697g
PDF
/
Buying Options
Total Price: USD $98.9
Unit Price: USD $98.89975
≥1 USD $98.89975
≥10 USD $95.70965
≥100 USD $92.51955
≥500 USD $82.9483
Inventory: 1904
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 24.13mm
Height Seated (Max) 4.57mm
Technical
On Chip Data RAM 20kB
Non-Volatile Memory ROM (4kB)
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 5.00V
RAM (words) 10272
Low Power Mode YES
Boundary Scan YES
Address Bus Width 16
Data Bus Width 16b
Bit Size 16
Supply Current-Max 112mA
Number of Bits 16
RAM Size 20.1kB
Memory Size 4kB
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Interface Serial Port
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 132
Base Part Number 320C50
Frequency 57MHz
Terminal Pitch 0.635mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Additional Feature 9K WORDS DATA/PROG RAM
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Fixed Point
ECCN Code 3A991.A.2
Number of Terminations 132
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
JESD-609 Code e4
Series TMS320C5x
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Weight 4.608697g
Number of Pins 132
Package / Case 132-BQFP Bumpered
Mounting Type Surface Mount
Mount Surface Mount
