TMS320BC52PZ100

Texas Instruments
RoHS
RoHS RoHS compliant
Package 100-LQFP
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description TMS320C5x MULTIPLE Contains Lead Surface Mount DSP 0C~70C TA ROM (8kB) 100MHz 1.6mm
PDF
/
Buying Options
Total Price: USD $26.82
Unit Price: USD $26.8204
≥1 USD $26.8204
≥10 USD $22.00675
≥100 USD $21.31895
≥500 USD $20.63115
≥1000 USD $19.94335
Inventory: 6907
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant

Dimensions

Thickness 1.4mm
Width 14mm
Length 14mm
Height 1.6mm

Technical

On Chip Data RAM 2kB
Non-Volatile Memory ROM (8kB)
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 5.00V
RAM (words) 1056
Low Power Mode YES
Boundary Scan YES
Bit Size 16
Interface BSP, SSP
Supply Voltage-Min (Vsup) 4.75V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.25V
Qualification Status Not Qualified
Pin Count 100
Base Part Number TMS320BC52
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 100MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Fixed Point
ECCN Code 3A001.A.3
Number of Terminations 100
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series TMS320C5x
Packaging Tray
Operating Temperature 0°C~70°C TA

Physical

Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
