SM32C6416TGLZA8EP
RoHS
RoHS compliant
RoHS compliantPackage 532-BFBGA, FCBGA
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
TMS320C6414T/15T/16T MULTIPLE Contains Lead Surface Mount DSP -40C~105C TC 32b 850MHz 3.131403g
PDF
/
Buying Options
Total Price: USD $1253.98
Unit Price: USD $1253.978819
≥1 USD $1253.978819
≥10 USD $1212.745476
≥25 USD $1204.315268
≥50 USD $1195.943664
≥100 USD $1171.345411
≥500 USD $1087.600193
Inventory: 5865
Minimum: 1
-
+
Technical Details
Technical
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Pin Count 532
Base Part Number 32C6416
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 850MHz
Reach Compliance Code not_compliant
Terminal Pitch 0.8mm
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Type Fixed Point
ECCN Code 3A001.A.3
Number of Terminations 532
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code no
Series TMS320C6414T/15T/16T
Packaging Tray
Operating Temperature -40°C~105°C TC
On Chip Data RAM 1.03MB
Voltage - Core 1.25V
Non-Volatile Memory External
Internal Bus Architecture MULTIPLE
Barrel Shifter NO
Voltage - I/O 3.30V
Low Power Mode YES
Boundary Scan YES
Address Bus Width 23
Data Bus Width 32b
Bit Size 32
Number of I/O 16
Min Supply Voltage 1.16V
Max Supply Voltage 3.46V
Interface Host Interface, McBSP, PCI, UTOPIA
Power Supplies 1.23.3V
Physical
Weight 3.131403g
Number of Pins 532
Package / Case 532-BFBGA, FCBGA
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 23mm
Height Seated (Max) 3.25mm
