DSPB56374AF
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
DSP56K/Symphony MULTIPLE Surface Mount Audio Processor DSP 0C~70C TA ROM (84kB) 149.9MHz 14mm
PDF
/
Buying Options
Total Price: USD $10.78
Unit Price: USD $10.7844
≥1 USD $10.7844
≥10 USD $8.84925
≥100 USD $8.5728
≥500 USD $8.29635
≥1000 USD $8.0199
Inventory: 8708
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.6mm
Technical
Clock Rate 150MHz
On Chip Data RAM 54kB
Voltage - Core 1.25V
Non-Volatile Memory ROM (84kB)
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 3.30V
Format FIXED POINT
Low Power Mode YES
Boundary Scan YES
Clock Frequency 149.9MHz
Interface Host Interface, I2C, SAI, SPI
Supply Voltage-Min (Vsup) 1.2V
Supply Voltage-Max (Vsup) 1.3V
Qualification Status COMMERCIAL
JESD-30 Code S-PQFP-G80
Pin Count 80
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 1.25V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish MATTE TIN
Type Audio Processor
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series DSP56K/Symphony
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
