ADSP-21060LAB-160
RoHS
/
Package 225-BBGA
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
SHARC? MULTIPLE Surface Mount Floating Point DSP -40C~85C TC External 40MHz 23mm
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.95267
≥1 USD $0.95267
≥10 USD $0.898747
≥100 USD $0.847876
≥500 USD $0.799877
≥1000 USD $0.754604
Inventory: 3537
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 23mm
Length 23mm
Height Seated (Max) 2.7mm
Technical
Clock Rate 40MHz
On Chip Data RAM 512kB
Non-Volatile Memory External
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Voltage - I/O 3.30V
External Data Bus Width 48
Low Power Mode YES
Boundary Scan YES
Address Bus Width 32
Clock Frequency 40MHz
Interface Host Interface, Link Port, Serial Port
Supply Voltage-Min (Vsup) 3.15V
Supply Voltage-Max (Vsup) 3.45V
Qualification Status COMMERCIAL
JESD-30 Code S-PBGA-B225
Pin Count 225
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Terminal Finish TIN LEAD SILVER
Type Floating Point
Number of Terminations 225
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series SHARC?
Packaging Tray
Operating Temperature -40°C~85°C TC
Physical
Surface Mount YES
Package / Case 225-BBGA
Mounting Type Surface Mount
