ADSP-21060CZ-133
RoHS
RoHS compliant
RoHS compliantPackage 240-BFCQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description
SHARC? MULTIPLE Surface Mount Floating Point DSP -40C~100C TC External 33.3MHz 32mm
PDF
/
Inventory: 8841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 240-BFCQFP Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~100°C TC
Packaging Tray
Series SHARC?
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 240
Type Floating Point
Terminal Finish GOLD OVER NICKEL
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 240
JESD-30 Code S-CQFP-G240
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Interface Host Interface, Link Port, Serial Port
Clock Frequency 33.3MHz
Address Bus Width 32
Boundary Scan YES
Low Power Mode YES
External Data Bus Width 48
Voltage - I/O 5.00V
Barrel Shifter YES
Internal Bus Architecture MULTIPLE
Non-Volatile Memory External
On Chip Data RAM 512kB
Clock Rate 33MHz
Dimensions
Height Seated (Max) 4.3mm
Length 32mm
Width 32mm
Compliance
RoHS Status ROHS3 Compliant
