XC9536-5CSG48C
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL COMMERCIAL CMOS BALL complex programmable logic device 70C 5V 5ns 7mm
PDF
/
Buying Options
Total Price: USD $37.33
Unit Price: USD $37.32645
≥1 USD $37.32645
≥10 USD $30.62705
≥100 USD $29.6704
≥500 USD $28.7128
≥1000 USD $27.75615
Inventory: 3157
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
In-System Programmable YES
JTAG BST YES
Number of Macro Cells 36
Output Function MACROCELL
Speed Grade 5
Number of Logic Blocks (LABs) 8
Organization 0 DEDICATED INPUTS, 34 I/O
Frequency (Max) 100MHz
Propagation Delay 5 ns
Memory Type FLASH
Number of I/O 34
Temperature Grade COMMERCIAL
Operating Supply Voltage 5V
Pin Count 48
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature YES
Min Operating Temperature 0°C
Max Operating Temperature 70°C
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3
Pbfree Code yes
JESD-609 Code e1
Physical
Number of Pins 48
Surface Mount YES
