XCR3032XL-7CS48C
RoHS
/
Package 48-FBGA, CSPBGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 48-FBGA CSPBGA 2003 XCR3032XL complex programmable logic device 119MHz 1.8mm 7.5ns 3V~3.6V
PDF
/
Buying Options
Total Price: USD $9.24
Unit Price: USD $9.238877
≥1 USD $9.238877
≥200 USD $3.57634
≥416 USD $3.450301
≥832 USD $3.388595
Inventory: 952
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 1.8mm
Technical
Delay Time tpd(1) Max 7ns
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 32
Output Function MACROCELL
Speed Grade 7
Max Frequency 119MHz
Number of Gates 750
Number of Logic Elements/Cells 2
Turn On Delay Time 7.5 ns
Propagation Delay 7.5 ns
Memory Type EEPROM
Number of I/O 36
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Programmable Type In System Programmable (min 1K program/erase cycles)
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 48
Base Part Number XCR3032XL
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 240
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature YES
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Series CoolRunner XPLA3
Published 2003
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 48
Package / Case 48-FBGA, CSPBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Lead, Tin
Supply Chain
Factory Lead Time 10 Weeks
