XC9572XL-5PC44C
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Obsolete Surface Mount Not Qualified CPLD 0C~70C TA 3V~3.6V 5ns 1.27mm
PDF
/
Buying Options
Total Price: USD $4.96
Unit Price: USD $4.9571
≥1 USD $4.9571
≥10 USD $4.06695
≥100 USD $3.93965
≥500 USD $3.8133
≥1000 USD $3.686
Inventory: 1573
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 72
Output Function MACROCELL
Speed Grade 5
Max Frequency 178.6MHz
Number of Gates 1600
Number of Logic Elements/Cells 4
Propagation Delay 5 ns
Memory Type FLASH
Number of I/O 34
Programmable Type In System Programmable (min 10K program/erase cycles)
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 44
Base Part Number XC9572XL
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 225
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series XC9500XL
Published 1996
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 44
Package / Case 44-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
