XC9536XL-5VQG64C
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 64-TQFP 1996 XC9536XL complex programmable logic device 178.6MHz 10mm 5ns 3V~3.6V
PDF
/
Buying Options
Total Price: USD $3.45
Unit Price: USD $3.44945
≥1 USD $3.44945
≥10 USD $2.83005
≥100 USD $2.7417
≥500 USD $2.65335
≥1000 USD $2.565
Inventory: 8242
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Technical
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 36
Output Function MACROCELL
Speed Grade 5
Max Frequency 178.6MHz
Number of Gates 800
Number of Logic Elements/Cells 2
Propagation Delay 5 ns
Memory Type FLASH
Number of I/O 36
Programmable Type In System Programmable (min 10K program/erase cycles)
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 64
Base Part Number XC9536XL
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature YES
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series XC9500XL
Published 1996
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 64
Package / Case 64-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
