XC9536XL-10PC44I
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Obsolete Surface Mount CMOS CPLD -40C~85C TA 3V~3.6V 10ns 100MHz
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.610871
≥1 USD $0.610871
≥10 USD $0.5763
≥100 USD $0.54367
≥500 USD $0.5129
≥1000 USD $0.483861
Inventory: 1325
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Lead, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1996
Series XC9500XL
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 225
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number XC9536XL
Pin Count 44
Operating Supply Voltage 3.3V
Programmable Type In System Programmable (min 10K program/erase cycles)
Max Supply Voltage 3.6V
Min Supply Voltage 3V
Number of I/O 34
Memory Type FLASH
Propagation Delay 10 ns
Turn On Delay Time 10 ns
Number of Logic Elements/Cells 2
Number of Gates 800
Max Frequency 100MHz
Speed Grade 10
Output Function MACROCELL
Number of Macro Cells 36
JTAG BST YES
Voltage Supply - Internal 3V~3.6V
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
