ATF1508ASV-15AU100-T
RoHS
/
Package 100-TQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
100-TQFP ATF1508ASV ATF15xx S-PQFP-G100 complex programmable logic device 100MHz 14mm 15ns 3V~3.6V
PDF
/
Buying Options
Total Price: USD $5.42
Unit Price: USD $5.4208
≥1 USD $5.4208
≥10 USD $4.9808
≥100 USD $4.774
Inventory: 441
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Delay Time tpd(1) Max 15ns
Voltage Supply - Internal 3V~3.6V
Number of Macro Cells 128
Output Function MACROCELL
Propagation Delay 15 ns
Clock Frequency 100MHz
Number of I/O 80
Programmable Type In System Programmable (min 10K program/erase cycles)
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G100
Base Part Number ATF1508ASV
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series ATF15xx
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 100-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
