M4A5-32/32-5JNC
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 44-LCC (J-Lead) 1998 M4A5-32 complex programmable logic device 182MHz 16.5862mm 5ns 5V
PDF
/
Inventory: 8463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 1998
Series ispMACH? 4A
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number M4A5-32
Pin Count 44
JESD-30 Code S-PQCC-J44
Qualification Status Not Qualified
Power Supplies 5V
Programmable Type In System Programmable
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Number of I/O 32
Memory Type EEPROM
Propagation Delay 5 ns
Number of Gates 1250
Max Frequency 182MHz
Output Function MACROCELL
Number of Macro Cells 32
JTAG BST YES
Voltage Supply - Internal 4.75V~5.25V
Delay Time tpd(1) Max 5ns
Dimensions
Height Seated (Max) 4.572mm
Length 16.5862mm
Width 16.5862mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
