LC4512B-75T176I
RoHS
/
Package 176-LQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
176-TQFP (24x24) 2000 LC4512 ispMACH? 4000B complex programmable logic device 322MHz 14mA 7.5ns 2.3V~2.7V
PDF
/
Inventory: 7256
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 176-LQFP
Number of Pins 176
Supplier Device Package 176-TQFP (24x24)
Technical
Operating Temperature -40°C~105°C TJ
Packaging Tray
Published 2000
Series ispMACH? 4000B
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Base Part Number LC4512
Operating Supply Voltage 2.5V
Programmable Type In System Programmable
Max Supply Voltage 2.7V
Min Supply Voltage 2.3V
Operating Supply Current 14mA
Number of I/O 128
Nominal Supply Current 14mA
Memory Type EEPROM
Max Frequency 322MHz
Number of Programmable I/O 48
Number of Logic Blocks (LABs) 32
Number of Macro Cells 512
Voltage Supply - Internal 2.3V~2.7V
Delay Time tpd(1) Max 7.5ns
Number of Logic Elements/Blocks 32
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
