LC4384C-5F256I
RoHS
/
Package 256-BGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 256-BGA 2000 LC4384 complex programmable logic device 156MHz 17mm 5ns 1.8V
PDF
/
Inventory: 7649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 17mm
Length 17mm
Height Seated (Max) 2.1mm
Technical
Number of Logic Elements/Blocks 24
Delay Time tpd(1) Max 5ns
Voltage Supply - Internal 1.65V~1.95V
Number of Dedicated Inputs 4
JTAG BST YES
Number of Macro Cells 384
Output Function MACROCELL
Propagation Delay 5 ns
Clock Frequency 156MHz
Number of I/O 192
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 1.65V
Power Supplies 1.8V
Supply Voltage-Max (Vsup) 1.95V
Qualification Status Not Qualified
JESD-30 Code S-PBGA-B256
Pin Count 256
Base Part Number LC4384
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 1mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Series ispMACH? 4000C
Published 2000
Packaging Tray
Operating Temperature -40°C~105°C TJ
Physical
Surface Mount YES
Package / Case 256-BGA
Mounting Type Surface Mount
