ISPLSI 2096VE-135LTN128
RoHS
RoHS compliant
RoHS compliantPackage 128-LQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 128-LQFP 2000 ISPLSI 2096 complex programmable logic device 100MHz 14mm 7.5ns 3.3V
PDF
/
Inventory: 4240
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 128-LQFP
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2000
Series ispLSI? 2000VE
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 128
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ISPLSI 2096
Pin Count 128
JESD-30 Code S-PQFP-G128
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 3V
Programmable Type In System Programmable
Number of I/O 96
Clock Frequency 100MHz
Propagation Delay 10 ns
Number of Gates 4000
Output Function MACROCELL
Number of Macro Cells 96
JTAG BST NO
Number of Dedicated Inputs 2
Voltage Supply - Internal 3V~3.6V
Delay Time tpd(1) Max 7.5ns
Number of Logic Elements/Blocks 24
Dimensions
Height Seated (Max) 1.6mm
Length 14mm
Width 14mm
Compliance
RoHS Status RoHS Compliant
