ISPLSI 2096A-100LQN128
RoHS
RoHS compliant
RoHS compliantPackage 128-BQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 128-BQFP 2000 ISPLSI 2096 complex programmable logic device 77MHz 28mm 10ns 5V
PDF
/
Inventory: 5680
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 128-BQFP
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2000
Series ispLSI? 2000A
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 128
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Terminal Pitch 0.8mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ISPLSI 2096
Pin Count 128
JESD-30 Code S-PQFP-G128
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Programmable Type In System Programmable
Number of I/O 96
Clock Frequency 77MHz
Propagation Delay 13 ns
Number of Gates 4000
Output Function MACROCELL
Number of Macro Cells 96
JTAG BST NO
Number of Dedicated Inputs 3
Voltage Supply - Internal 4.75V~5.25V
Delay Time tpd(1) Max 10ns
Number of Logic Elements/Blocks 24
Dimensions
Height Seated (Max) 4.1mm
Length 28mm
Width 28mm
Compliance
RoHS Status RoHS Compliant
