ISPLSI 1016EA-200LT44
RoHS
/
Package 44-TQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 44-TQFP 2002 ISPLSI 1016 complex programmable logic device 143MHz 10mm 4.5ns 5V
PDF
/
Inventory: 945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Published 2002
Series ispLSI? 1000EA
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish TIN LEAD
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ISPLSI 1016
Pin Count 44
JESD-30 Code S-PQFP-G44
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.75V
Programmable Type In System Programmable
Number of I/O 32
Clock Frequency 143MHz
Propagation Delay 6 ns
Number of Gates 2000
Output Function MACROCELL
Number of Macro Cells 64
JTAG BST NO
Voltage Supply - Internal 4.75V~5.25V
Delay Time tpd(1) Max 4.5ns
Number of Logic Elements/Blocks 16
Dimensions
Length 10mm
Width 10mm
Compliance
RoHS Status Non-RoHS Compliant
