GAL20V8B-15LJN
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
REGISTER PRELOAD; POWER-UP RESET 28-LCC (J-Lead) 1996 GAL20V8 complex programmable logic device 62.5MHz 90mA 11.5062mm 90mA
PDF
/
Buying Options
Total Price: USD $3.23
Unit Price: USD $3.22715
≥1 USD $3.22715
≥10 USD $2.64765
≥100 USD $2.565
≥500 USD $2.48235
≥1000 USD $2.3997
Inventory: 7160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 11.5062mm
Length 11.5062mm
Height Seated (Max) 4.572mm
Technical
Number of Product Terms 64
Voltage Supply - Internal 4.75V~5.25V
Number of Dedicated Inputs 12
Number of Macro Cells 8
Output Function MACROCELL
Number of Inputs 20
Architecture PAL-TYPE
Turn On Delay Time 15 ns
Propagation Delay 15 ns
Max Supply Current 90mA
Nominal Supply Current 90mA
Number of I/O 8
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type EE PLD
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 8
Pin Count 28
Base Part Number GAL20V8
Time@Peak Reflow Temperature-Max (s) 40
Frequency 62.5MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature REGISTER PRELOAD; POWER-UP RESET
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series GAL?20V8
Published 1996
Packaging Tube
Operating Temperature 0°C~75°C TA
Physical
Number of Pins 28
Package / Case 28-LCC (J-Lead)
Mounting Type Surface Mount
Mount Surface Mount
