GAL16V8D-7LJ
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
PROGRAMMABLE OUTPUT POLARITY 20-LCC (J-Lead) 2000 GAL16V8 complex programmable logic device 125MHz 115mA 8.96mm 7.5ns
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 1630
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Number of Pins 20
Technical
Operating Temperature 0°C~75°C TA
Packaging Bulk
Published 2000
Series GAL?16V8
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Additional Feature PROGRAMMABLE OUTPUT POLARITY
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 225
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 125MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number GAL16V8
Pin Count 20
Number of Outputs 8
Operating Supply Voltage 5V
Power Supplies 5V
Programmable Type EE PLD
Voltage 5V
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Number of I/O 8
Nominal Supply Current 115mA
Propagation Delay 7.5 ns
Turn On Delay Time 7.5 ns
Architecture PAL-TYPE
Output Function MACROCELL
Number of Macro Cells 8
Number of Dedicated Inputs 8
Voltage Supply - Internal 4.75V~5.25V
Number of Product Terms 64
