EPM7256AEFC256-10N
RoHS
RoHS compliant
RoHS compliantPackage 256-BGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 256-BGA EPM7256 MAX? 7000A complex programmable logic device 95.2MHz 17mm 10ns 2.5/3.33.3V
PDF
/
Buying Options
Total Price: USD $34.9
Unit Price: USD $34.903
≥1 USD $34.903
≥10 USD $28.6387
≥100 USD $27.7438
≥500 USD $26.8489
≥1000 USD $25.954
Inventory: 873
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 17mm
Length 17mm
Height Seated (Max) 2.1mm
Technical
Number of Logic Elements/Blocks 16
Delay Time tpd(1) Max 10ns
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 256
Output Function MACROCELL
Number of Gates 5000
Propagation Delay 10 ns
Clock Frequency 95.2MHz
Number of I/O 164
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 3V
Power Supplies 2.5/3.33.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Base Part Number EPM7256
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Terminal Finish TIN SILVER COPPER
ECCN Code 3A991
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e1
Series MAX? 7000A
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 256-BGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
