EPM7064SLC84-6
RoHS
/
Package 84-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V 84-LCC (J-Lead) EPM7064 MAX? 7000S complex programmable logic device 200MHz 29.3116mm 6ns 3.3/55V
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0285
≥1 USD $0.0285
≥10 USD $0.0228
≥100 USD $0.0228
≥500 USD $0.02185
≥1000 USD $0.0209
≥10000 USD $0.019
Inventory: 1371
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 84-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C TA
Packaging Tray
Series MAX? 7000S
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 84
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 220
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number EPM7064
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 3.3/55V
Programmable Type In System Programmable
Number of I/O 68
Clock Frequency 200MHz
Propagation Delay 6 ns
Number of Gates 1250
Output Function MACROCELL
Number of Macro Cells 64
JTAG BST YES
Voltage Supply - Internal 4.75V~5.25V
Delay Time tpd(1) Max 6ns
Number of Logic Elements/Blocks 4
Dimensions
Height Seated (Max) 5.08mm
Length 29.3116mm
Width 29.3116mm
Compliance
RoHS Status Non-RoHS Compliant
