EPM7032AELC44-7
RoHS
/
Package 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
44-LCC (J-Lead) EPM7032 MAX? 7000A Tin/Lead (Sn/Pb) complex programmable logic device 138.9MHz 4.57mm 7.5ns 3V~3.6V
PDF
/
Buying Options
Total Price: USD $4.08
Unit Price: USD $4.0774
≥1 USD $4.0774
≥10 USD $3.34495
≥100 USD $3.24045
≥500 USD $3.13595
≥1000 USD $3.03145
Inventory: 8006
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 4.57mm
Technical
Number of Logic Elements/Blocks 2
Delay Time tpd(1) Max 7.5ns
Voltage Supply - Internal 3V~3.6V
JTAG BST YES
Number of Macro Cells 32
Output Function MACROCELL
Number of Gates 600
Propagation Delay 7.5 ns
Clock Frequency 138.9MHz
Number of I/O 36
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-J44
Base Part Number EPM7032
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 220
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Series MAX? 7000A
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 44-LCC (J-Lead)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
