EPM570GT144I5
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 144-LQFP EPM570 MAX? II complex programmable logic device 20mm 5.4ns 1.5/3.31.8V 1.71V~1.89V
PDF
/
Buying Options
Total Price: USD $341.61
Unit Price: USD $341.608863
≥1 USD $341.608863
≥10 USD $322.272516
≥100 USD $304.030678
≥500 USD $286.821393
≥1000 USD $270.586218
Inventory: 1599
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 20mm
Length 20mm
Height Seated (Max) 1.6mm
Technical
Number of Logic Elements/Blocks 570
Delay Time tpd(1) Max 5.4ns
Voltage Supply - Internal 1.71V~1.89V
JTAG BST YES
Number of Macro Cells 440
Output Function MACROCELL
Propagation Delay 8.7 ns
Number of I/O 116
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 1.71V
Power Supplies 1.5/3.31.8V
Supply Voltage-Max (Vsup) 1.89V
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G144
Base Part Number EPM570
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 220
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 144
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e0
Series MAX? II
Packaging Tray
Operating Temperature -40°C~100°C TJ
Physical
Surface Mount YES
Package / Case 144-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
