EPM570GF256C4
RoHS
/
Package 256-BGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 256-BGA EPM570 MAX? II complex programmable logic device 17mm 5.4ns 1.5/3.31.8V 1.71V~1.89V
PDF
/
Buying Options
Total Price: USD $283.45
Unit Price: USD $283.452585
≥1 USD $283.452585
≥10 USD $267.408101
≥100 USD $252.27179
≥500 USD $237.992248
≥1000 USD $224.520991
Inventory: 1481
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 17mm
Length 17mm
Height Seated (Max) 2.2mm
Technical
Number of Logic Elements/Blocks 570
Delay Time tpd(1) Max 5.4ns
Voltage Supply - Internal 1.71V~1.89V
JTAG BST YES
Number of Macro Cells 440
Output Function MACROCELL
Propagation Delay 7 ns
Number of I/O 160
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 1.71V
Power Supplies 1.5/3.31.8V
Supply Voltage-Max (Vsup) 1.89V
Qualification Status Not Qualified
JESD-30 Code S-PBGA-B256
Base Part Number EPM570
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 220
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 256
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e0
Series MAX? II
Packaging Tray
Operating Temperature 0°C~85°C TJ
Physical
Surface Mount YES
Package / Case 256-BGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
