EPM240F100C4N
RoHS
RoHS compliant
RoHS compliantPackage 100-LBGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
IT CAN ALSO OPERATE AT 3.3V 100-LBGA EPM240 MAX? II complex programmable logic device 11mm 4.7ns 1.5/3.32.5/3.3V 2.5V 3.3V
PDF
/
Buying Options
Total Price: USD $20.75
Unit Price: USD $20.75085
≥1 USD $20.75085
≥10 USD $17.02685
≥100 USD $16.49485
≥500 USD $15.96285
≥1000 USD $15.43085
Inventory: 7607
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 100-LBGA
Surface Mount YES
Technical
Operating Temperature 0°C~85°C TJ
Packaging Tray
Series MAX? II
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
ECCN Code EAR99
Terminal Finish TIN SILVER COPPER
Additional Feature IT CAN ALSO OPERATE AT 3.3V
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.5V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number EPM240
JESD-30 Code S-PBGA-B100
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 2.625V
Power Supplies 1.5/3.32.5/3.3V
Supply Voltage-Min (Vsup) 2.375V
Programmable Type In System Programmable
Number of I/O 80
Propagation Delay 6.1 ns
Output Function MACROCELL
Number of Macro Cells 192
JTAG BST YES
Voltage Supply - Internal 2.5V 3.3V
Delay Time tpd(1) Max 4.7ns
Number of Logic Elements/Blocks 240
Dimensions
Height Seated (Max) 1.7mm
Length 11mm
Width 11mm
Compliance
RoHS Status RoHS Compliant
