EPM2210GF256I5
RoHS
/
Package 256-BGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
YES 256-BGA EPM2210 MAX? II complex programmable logic device 17mm 7ns 1.5/3.31.8V 1.71V~1.89V
PDF
/
Buying Options
Total Price: USD $6.19
Unit Price: USD $6.187515
≥1 USD $6.187515
≥10 USD $5.837282
≥100 USD $5.506869
≥500 USD $5.195165
≥1000 USD $4.901091
Inventory: 6107
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 256-BGA
Surface Mount YES
Technical
Operating Temperature -40°C~100°C TJ
Packaging Tray
Series MAX? II
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 256
ECCN Code 3A991
Terminal Finish TIN LEAD
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 220
Supply Voltage 1.8V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number EPM2210
JESD-30 Code S-PBGA-B256
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 1.89V
Power Supplies 1.5/3.31.8V
Supply Voltage-Min (Vsup) 1.71V
Programmable Type In System Programmable
Number of I/O 204
Propagation Delay 11.2 ns
Output Function MACROCELL
Number of Macro Cells 1700
JTAG BST YES
Voltage Supply - Internal 1.71V~1.89V
Delay Time tpd(1) Max 7ns
Number of Logic Elements/Blocks 2210
Dimensions
Height Seated (Max) 2.2mm
Length 17mm
Width 17mm
Compliance
RoHS Status Non-RoHS Compliant
