PALC22V10D-7JC
RoHS
/
Package PLCC
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Surface Mount COMMERCIAL EXTENDED PAL-TYPE complex programmable logic device 75C 5.25V 5V 7.5ns
PDF
/
Inventory: 6627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Number of Product Terms 132
Number of Dedicated Inputs 11
Output Function MACROCELL
Programmable Logic Type FLASH PLD
Organization 11 DEDICATED INPUTS, 10 I/O
Architecture PAL-TYPE
Frequency (Max) 166MHz
Propagation Delay 7.5 ns
Nominal Supply Current 140mA
Number of I/O 10
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL EXTENDED
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 10
Pin Count 28
Time@Peak Reflow Temperature-Max (s) 30
Frequency 166MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 225
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature 10 MACROCELLS; 1 EXTERNAL CLOCK; SHARED INPUT/CLOCK; VARIABLE PRODUCT TERMS
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 28
JESD-609 Code e0
Physical
Number of Pins 28
Package / Case PLCC
Mount Surface Mount
