CY37128P100-100AXC
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
100-LQFP 2003 CY37128 Ultra37000? complex programmable logic device 100MHz 14mm 10muA 12ns
PDF
/
Buying Options
Total Price: USD $55.3
Unit Price: USD $55.29855
≥1 USD $55.29855
≥10 USD $45.3739
≥100 USD $43.95555
≥500 USD $42.53815
≥1000 USD $41.1198
Inventory: 1114
Minimum: 1
-
+
Technical Details
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.6mm
Technical
Voltage Supply - Internal 4.75V~5.25V
Number of Dedicated Inputs 1
JTAG BST YES
Number of Macro Cells 128
Output Function MACROCELL
Number of Logic Blocks (LABs) 8
Number of Gates 3800
Turn On Delay Time 12 ns
Propagation Delay 12 ns
Max Supply Current 10μA
Memory Type EEPROM
Number of I/O 69
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Programmable Type In-System Reprogrammable? (ISR?) CMOS
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 100
Base Part Number CY37128
Time@Peak Reflow Temperature-Max (s) 20
Frequency 100MHz
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Subcategory Programmable Logic Devices
Terminal Finish Matte Tin (Sn)
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series Ultra37000?
Published 2003
Packaging Tray
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
