5962-9759901QZC
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Surface Mount MILITARY CMOS complex programmable logic device 125C 5.5V 5V 20ns
PDF
/
Inventory: 7522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Number of Pins 160
Technical
Published 2004
JESD-609 Code e4
Number of Terminations 160
ECCN Code 3A001.A.2.C
Terminal Finish GOLD
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature FOR SHIPPING METHOD CONTACT SALES
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.65mm
Pin Count 160
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade MILITARY
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of I/O 128
Memory Type FLASH
Clock Frequency 50MHz
Propagation Delay 20 ns
Turn On Delay Time 20 ns
Number of Logic Blocks (LABs) 8
Output Function MACROCELL
Number of Macro Cells 128
JTAG BST NO
Number of Dedicated Inputs 1
In-System Programmable YES
Dimensions
Height Seated (Max) 2.79mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
