EPM9480RC240-15
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Discontinued Surface Mount COMMERCIAL CPLD 70C 5V 3.3/55V 16.4ns
PDF
/
Buying Options
Total Price: USD $177.06
Unit Price: USD $177.0648
≥1 USD $177.0648
Inventory: 693
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Technical
Published 1994
JESD-609 Code e0
Pbfree Code no
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3
Number of Terminations 240
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature 676 FLIP FLOPS; CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 240
JESD-30 Code S-PQFP-G240
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.25V
Power Supplies 3.3/55V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 4.75V
Number of I/O 175
Clock Frequency 117.6MHz
Propagation Delay 16.4 ns
Programmable Logic Type EE PLD
Number of Gates 10000
Number of Logic Blocks (LABs) 30
Output Function MACROCELL
Number of Macro Cells 480
JTAG BST YES
In-System Programmable YES
