EPM7256AQC208-12
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL COMMERCIAL Not Qualified CMOS complex programmable logic device 70C 3.3V 2.5/3.33.3V 12ns
PDF
/
Buying Options
Total Price: USD $15.25
Unit Price: USD $15.2504
≥1 USD $15.2504
Inventory: 369
Minimum: 1
-
+
Technical Details
Physical
Package / Case PQFP
Surface Mount YES
Technical
JESD-609 Code e0
Pbfree Code no
Moisture Sensitivity Level (MSL) 3
Number of Terminations 208
ECCN Code 3A991
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 208
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2.5/3.33.3V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 3V
Number of I/O 164
Clock Frequency 78.1MHz
Propagation Delay 12 ns
Programmable Logic Type EE PLD
Number of Gates 5000
Number of Logic Blocks (LABs) 16
Output Function MACROCELL
Number of Macro Cells 256
JTAG BST YES
In-System Programmable YES
Dimensions
Height Seated (Max) 4.1mm
Length 28mm
Width 28mm
Compliance
RoHS Status Non-RoHS Compliant
