EPM7128ELC84-15
RoHS
/
Package PLCC
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Active Surface Mount COMMERCIAL CPLD 70C 5.25V 15ns 29.3116mm
PDF
/
Buying Options
Total Price: USD $29.21
Unit Price: USD $29.2136
≥1 USD $29.2136
≥10 USD $27.56
≥100 USD $26
≥500 USD $24.5283
≥1000 USD $23.13991
≥3000 USD $21.8301
Inventory: 6499
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 29.3116mm
Length 29.3116mm
Technical
In-System Programmable NO
JTAG BST NO
Number of Macro Cells 128
Output Function MACROCELL
Speed Grade 15
Number of Logic Blocks (LABs) 8
Number of Programmable I/O 68
Number of Gates 2500
Programmable Logic Type EE PLD
Frequency (Max) 125MHz
Turn On Delay Time 15 ns
Propagation Delay 15 ns
Memory Type EEPROM
Number of I/O 68
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL
Operating Supply Voltage 5V
Pin Count 84
Time@Peak Reflow Temperature-Max (s) 30
Frequency 100MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 220
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 84
Moisture Sensitivity Level (MSL) 2
Part Status Active
Pbfree Code no
JESD-609 Code e0
Published 1998
Physical
Number of Pins 84
Package / Case PLCC
Mount Surface Mount
