EPM570T144C4N
RoHS
/
Package TQFP
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Active Surface Mount OTHER CPLD 85C 1kB 3.6V 7ns
PDF
/
Buying Options
Total Price: USD $50.07
Unit Price: USD $50.072
≥1 USD $50.072
≥10 USD $48.101152
≥100 USD $45.126752
Inventory: 201
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Package / Case TQFP
Number of Pins 144
Technical
Packaging Bulk
Published 2003
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3
Number of Terminations 144
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature 0°C
Additional Feature IT CAN ALSO OPERATE AT 3.3V
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.5V
Terminal Pitch 0.5mm
Frequency 2.3148GHz
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 144
Operating Supply Voltage 3.3V
Temperature Grade OTHER
Max Supply Voltage 3.6V
Min Supply Voltage 2.375V
Memory Size 1kB
Operating Supply Current 55mA
Number of I/O 116
Nominal Supply Current 55mA
Memory Type FLASH
Propagation Delay 7 ns
Turn On Delay Time 7 ns
Frequency (Max) 304MHz
Number of Logic Elements/Cells 570
Number of Programmable I/O 116
Number of Logic Blocks (LABs) 57
Speed Grade 4
Output Function MACROCELL
Number of Macro Cells 440
JTAG BST YES
In-System Programmable YES
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
