EPM5192GM883B
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL MILITARY Not Qualified CMOS complex programmable logic device 125C 5V 5V 55ns
PDF
/
Inventory: 2730
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 28.45mm
Length 28.45mm
Height Seated (Max) 4.96mm
Technical
In-System Programmable NO
Number of Dedicated Inputs 7
JTAG BST NO
Number of Macro Cells 192
Output Function MACROCELL
Screening Level 38535Q/M;38534H;883B
Programmable Logic Type UV PLD
Organization 7 DEDICATED INPUTS, 64 I/O
Propagation Delay 55 ns
Clock Frequency 33.3MHz
Number of I/O 64
Temperature Grade MILITARY
Power Supplies 5V
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Qualification Status Not Qualified
JESD-30 Code S-CPGA-P84
Pin Count 84
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 2.54mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 220
Terminal Form PIN/PEG
Terminal Position PERPENDICULAR
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature LABS INTERCONNECTED BY PIA; 12 LABS; 192 MACROCELLS; 1 EXTERNAL CLOCK; SHARED INPUT/CLOCK
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 3A001.A.2.C
Number of Terminations 84
Pbfree Code no
JESD-609 Code e0
Physical
Surface Mount NO
