EPM5192GM883B-2
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL MILITARY Not Qualified CMOS complex programmable logic device 125C 5V 5V 45ns
PDF
/
Inventory: 4202
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Technical
JESD-609 Code e0
Number of Terminations 84
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature LABS INTERCONNECTED BY PIA; 12 LABS; 192 MACROCELLS; 1 EXTERNAL CLOCK; SHARED INPUT/CLOCK
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position PERPENDICULAR
Terminal Form PIN/PEG
Supply Voltage 5V
Terminal Pitch 2.54mm
Pin Count 84
JESD-30 Code S-CPGA-P84
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
Power Supplies 5V
Temperature Grade MILITARY
Number of I/O 64
Clock Frequency 40MHz
Propagation Delay 45 ns
Organization 7 DEDICATED INPUTS, 64 I/O
Programmable Logic Type UV PLD
Screening Level MIL-STD-883 Class B (Modified)
Output Function MACROCELL
Number of Macro Cells 192
JTAG BST NO
Number of Dedicated Inputs 7
In-System Programmable NO
Dimensions
Height Seated (Max) 4.96mm
Length 28.45mm
Width 28.45mm
Compliance
RoHS Status Non-RoHS Compliant
