5M240ZM68C5
RoHS
/
Package TFBGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Surface Mount OTHER Not Qualified complex programmable logic device 85C 1.8V 1.81.2/3.3V 14ns
PDF
/
Inventory: 998
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case TFBGA
Number of Pins 68
Technical
JESD-609 Code e0
Pbfree Code no
Number of Terminations 68
ECCN Code EAR99
Terminal Finish TIN LEAD
Max Operating Temperature 85°C
Min Operating Temperature 0°C
Additional Feature YES
HTS Code 8542.39.00.01
Subcategory Programmable Logic Devices
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 235
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 68
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 1.89V
Power Supplies 1.81.2/3.3V
Temperature Grade OTHER
Supply Voltage-Min (Vsup) 1.71V
Number of I/O 52
Clock Frequency 118.3MHz
Propagation Delay 14 ns
Programmable Logic Type FLASH PLD
Number of Logic Blocks (LABs) 240
Output Function MACROCELL
Number of Macro Cells 192
JTAG BST YES
In-System Programmable YES
Dimensions
Height Seated (Max) 1.2mm
Length 5mm
Width 5mm
Compliance
RoHS Status RoHS Compliant
