5M2210ZF256C5N
RoHS
/
Package FBGA
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
MACROCELL Active Surface Mount OTHER CPLD 85C 1kB 1.89V 1.81.2/3.3V
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
≥3000 USD $8.94995
Inventory: 7704
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 17mm
Length 17mm
Height 1.25mm
Technical
In-System Programmable YES
JTAG BST YES
Number of Macro Cells 1700
Output Function MACROCELL
Number of Logic Blocks (LABs) 2210
Number of Programmable I/O 203
Frequency (Max) 304MHz
Propagation Delay 7 ns
Memory Type FLASH
Nominal Supply Current 2mA
Number of I/O 203
Operating Supply Current 2mA
Memory Size 1kB
Min Supply Voltage 1.71V
Max Supply Voltage 1.89V
Temperature Grade OTHER
Power Supplies 1.81.2/3.3V
Operating Supply Voltage 1.8V
Qualification Status Not Qualified
Pin Count 256
Time@Peak Reflow Temperature-Max (s) 40
Frequency 118.3MHz
Terminal Pitch 1mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Subcategory Programmable Logic Devices
HTS Code 8542.39.00.01
Additional Feature YES
Min Operating Temperature 0°C
Max Operating Temperature 85°C
Terminal Finish TIN SILVER COPPER
ECCN Code 3A991
Number of Terminations 256
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2003
Physical
Number of Pins 256
Package / Case FBGA
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
